HUSQVARNA P 525DX

Name: HUSQVARNA P 525DX
Brand: Husqvarna
SKU: 967 98 53‑01
Availability: InStock

SKU: 967 98 53‑01 Part No. 967 98 53‑01 $33,499.00

Category Riders

Share This Product

Description
Features
Specifications

Description

High-capacity diesel-powered front mower offering unbeatable manoeuvrability and productivity in complex and narrow environments as well as in larger-sized areas. The commercial graded transmission gives uncompromised traction and slope stability. The machine’s compact size and high transport speed makes it suitable both for stationary and mobile application for municipalities, contractors, housing agencies etc. Thanks to the front-mounted cutting deck the operator has perfect overview of the working area. This means optimised trimming ability as well as accessibility under benches, bushes etc. Long-life components for solid durability and less downtime. Attachments such as utility bucket and broom give increased productivity all-year round. The P525DX can be fitted with either a 132 or 155 cm Combi cutting deck. Snow thrower, folding plough & snow blade attachments not available in AU/NZ markets. *Price excludes deck. Decks supplied at additional cost.

Features

Patented articulated steering
Trimming ability
Mowing accessibility
Compact design
Commercial grade transmission
All-Wheel Drive (AWD)
Versatile usage
Cabin
All-Wheel-Drive (AWD)
Shaft PTO
Quick coupling
Kubota diesel engine
Ergonomic operation
Hydraulic power steering
Easy-access controls
Tilting hood
Greasable mandrels
Off-set cutting deck
Service position
Durable ladder frame
Cast iron rear wagon
Heavy-duty deck design
16 inch wheels
Ready for Combi deck

Specifications

Engine: P 525DX (2021-)
Art No: 967 98 53-01
Power/Fuel Type: Diesel
Net Power at Preset RPM: 17.8 kW
Net Power at Preset RPM (RPM): 3,000 rpm
Motor/Engine Manufacturer: Kubota
Engine Name: D1105
Cylinder Displacement: 1,123 cm³
Cylinders: 3
Engine Cooling: Liquid
Engine Lubrication Type: Pressure with Oilfilter
Oil Filter: Yes
Emission:
- Exhaust Emissions (CO₂ EU V): 1,018 g/kWh
Battery:
- Battery Capacity: 62 Ah
- Battery Type: Lead-Acid
- Battery Pack Weight: 14 kg
- Battery Manufacturer: Exide
Cutting Deck:
- Uncut Circle: 58 cm
- Cutting Width (Min): 132 cm
- Cutting Width (Max): 155 cm
- Cutting Height (Min): 30 mm
- Cutting Height (Max): 112 mm
- Blade Engagement: Electric clutch
Dimensions:
- Tyre Dimensions (Front): 20×10-10
- Tyre Dimensions (Rear): 20×10-10
- Wheelbase: 106 cm
- Ground Clearance: 140 mm
- Base Machine (Length): 207.8 cm
- Base Machine (Width): 115.3 cm
- Base Machine (Height): 133 cm
- Gross Weight Towed: 350 kg
- Weight (Excl. Cutting Equipment): 684 kg
Drive System:
- PTO (Power Take Off): Shaft drive
- Transmission Type: Hydrostatic
- Transmission Manufacturer (Rear): Kanzaki
- Drive Method: Dual pedal-operation
- Speed (Forward Max): 19 km/h
- Speed (Reverse Max): 9.3 mph / 15 km/h
- Transmission Manufacturer (Front): Kanzaki
- Transmission Model (Front): KTM 23LC
- Transmission Model (Rear): KTM 23SC
Equipment:
- Seat Suspension: Yes
- Seat Type: Full suspension, arm rests
- Hour Meter Type: Digital
- Seat Material: Vinyl
- Seat Back Height: High
- Foldable Seat: Yes
- Steering Wheel Type: Professional
- Parking Brake Type: Disc
Vibration:
- Vibration Level (Steering Wheel): 1.7 m/s²
- Vibration Level (Seat): 0.7 m/s²
Sound and Noise:
- Sound Pressure Level (at Operator’s Ear): 91 dB(A)
- Sound Power Level (Guaranteed – LWA): 105 dB(A)
- Sound Power Level (Measured): 104 dB(A)
